Fan blade for Govi unit
For the old type evaporator:
with horizontal fan motor
this draws over the blower motor
then through the old type evaporator:
Arktik 1600N
Arktik 2000N
New No. 4012261
Old No.
GVE-50.01.203
Tech. info:
Blower fan blade
Material:
5 blades
Ø25mm
Height 5mm
Blade type: suction, blade over the motor
Mounting with arrow direction on blade
on the motor side, then the operation is suction
over the fan motor, rotation direction
clockwise.
Mounting of stainless steel bolt M4 with washer
mount with locking compound,
which can still be loosened, see order together
Also fits the brands below with the
same connection and large blade:
Yanmis motors 33 Watt
Euro Motors Italia 25/85W
Elco fan motor VN5-13
evaporator fan motor ap361
FMI AA106640X - fan motor 25W
Elco NET3T25PVN004 - Fan motor ELCO 25W
