This Compressor model
QP16XS-QP16XD)
Is always supplied without crankcase oil
and magnetic coupling / Clutch
If necessary. The correct oil/coupling must be ordered separately.
See under: Order accessories.
Compressor for low temperatures.
For direct drive refrigeration systems.
Such as Carrier / Thermoking.
Frigosoft / Zanotti / Govet / Kerstner.
Konvecta / Davia / Cibin / Webasto.
Zexel/Tama/Valeo.
Air Conditioning Compressor Description:
QP16 OR Horizontal.
AC Compressor: QP16XS QP16HS (QP16HD).
Connection: O-ring.
Connection: Horizontal.
Compressor Info:
Capacity: 163cc.
Refrigerant: R134a / R404a.
Oil. Type: Supplied without oil
Oil quantity: 180 ml
See photo for our oil type
Connection Type: O-ring
Suction Coupling: (G10) 7/8" 14UNF
Pressure Coupling: (G8) 3/4" 16UNF
Mounting: 4 mounting ears
With hole size Ø10.3
Center distance: 104 mm
Cylinders: 6
Rotation: CW/CCW
Speed range: 700-6000 RPM
Compressor type:
Seltec/Zexel QP16XS / QP-16HS / QP16HD
Connection: O-ring
Housing type:Z0006401
W (mm) 39.5 mm / W (mm) 46.5 mm
C (mm) 83.3mm
Description on Air conditioning pump:
Seltec
HFC134a Model QP-16XS
Body No.
LUB. CM³
LEAK.TEST Hi/Lo:2.9/1.5 MPaG
Made in Japan
Net 7400 grams
According to the rules art.SAE-J639
