AC pump / Air conditioning compressor
NB!!! No oil in compressor included
QP13XD Air conditioning pump Que
Compressors 12V:
Description Air conditioning Compressor:
AC Compressor: QP13HD
Interchangeable for TM13HD
Refrigerant R134a
Displacement [cc] 131
Compressor Type QP 13
Voltage [V] 12
Number of grooves 8 Poly-V
Pulley Diameter [mm] 119
Fittings OR V.
Discharge fitting 3/4" 16UNF
Suction fitting 7/8" 14UNF
Oil Type PAG 46
Autoclima Oil code 80813043
Section Groove [mm] 3,56
Gauge final groove [mm] 46,5
Distance of fixing points [mm] 83,3
Oil type: According to vehicle specification
Possibly
See Order accessories
Air conditioning Car/Truck R134a inst.: AC-80813043
Carrier Transicold R134a/R404a :AC-656009500 (1L)
Thermo-King R134a/R404a :HP-203-513 (1L)
Amount of oil filled
should be: 150ml
W (mm) 46.5mm
C (mm) 83.3mm
Description on item:
Logo QUE
QP13HD-1272
Made in China
7100 gram
Descriptions and adjustments below
and applications various article codes
It is forbidden to copy bottom texts
QP-13HD/QP13HD/QP-13XD
QP13XDQP-13HD/QP13HD
Compressor
OE CO-6095CAXD/CO6095CAXD
