Blower Spal Ø305mm 24V Blowing VA01-BP70/LL-36S 24V

Click on the images below for enlargements:

Accessories

Bracket for Spal Fan 4mm high

More information
On stock : 19 piece(s)
Amount:
Article code:
AC-30320001
Standard price:
2.70 (excl. VAT)
Online price:
2.57 (excl. VAT)3.11 (incl. VAT)

Support for Spal Fan 9mm high

More information
On stock : 22 piece(s)
Amount:
Article code:
AC-30320002
Standard price:
2.70 (excl. VAT)
Online price:
2.57 (excl. VAT)3.11 (incl. VAT)

Support Spal Fan 4mm high + mounting Strip 194mm

More information
On stock : 19 piece(s)
Amount:
Article code:
AC-30320014
Standard price:
3.78 (excl. VAT)
Online price:
3.59 (excl. VAT)4.34 (incl. VAT)

Support Spal Fan 9mm high + mounting Strip 194mm

More information
On stock : 8 piece(s)
Amount:
Article code:
AC-30320015
Standard price:
4.00 (excl. VAT)
Online price:
3.80 (excl. VAT)4.60 (incl. VAT)

Connector Blue Crimp Seal 2,5 qmm

More information
On stock : 81 piece(s)
Amount:
Article code:
LF-0002
Standard price:
1.13 (excl. VAT)
Online price:
1.08 (excl. VAT)1.30 (incl. VAT)

Connector Yellow Crimp Seal 4 qmm

More information
On stock : 52 piece(s)
Amount:
Article code:
LF-0003
Standard price:
1.10 (excl. VAT)
Online price:
1.04 (excl. VAT)1.26 (incl. VAT)
Article number:
AC-3010.2546
Price per piece:
120.00
Online price:
114.00 (excl. VAT)
137.94 (incl. VAT)
Amount:
On stock : 2 piece(s)
Spal Condenser Fan/Blower

Fan/Blower Ø305 mm VA01-BP70/LL36S
Proof tension 26V
Electric consumption (A)7,1 A
Air flow (m3/h)2760 m³/h
Voltage 24V
Type Fan Blowing
Diameter Ø 305 mm
Weight 2300 gr
Total diameter 330 mm
Thickness 95 mm
New Spal Code VA01BP70/LL-36S
Old Spal Code VA01-BP1-36S
Spal productor Code 3010.2546 / VA01BP70/LL36S
OE 0008383706 / 1E05244G02
282101001 / 60102
6278350307 / 68981C
781087 / 781295
81867B / A0008383706
A6278350307 / H11001215
160619 / 160908

Mercedes Nr./ No.Code:
A00-083837-06 / A0008383706
A00-08383706 / A62-783503-07
A6278350307 / A62-78350307
A00-283048-08 / A0028304808
A00-28304808

Sutrak Nr./ No.Code:
28,21,01,001 / 28.21.01.001
282101001 / 1,00,50,02,210
1.00.50.02.210 / 1005002210

Spal: Nr./ No.Code:
pal: Nr./ No.Code:
VA01-BP70/LL-36S / VA01BP70/LL36S
SP30102546 / VA01BP70LL36S
VA01-BP1-36S / VA01BP/136S / VA01BP136S

Autoclima:Nr./ No.Code:
30-315883-25 / 3031588325
30-31588325

Used on Airco unit
from Webasto C300
Catalog number:
VT1232S / 2990 331 305 94

Spal Fans Nederland

Old Artikelcode :
AC-3031588325

Description on Article:

Technical specifications:
AC-3010.2546.pdf


Spal type comparison:
Spal Type VA01.pdf















































































































































Applications and Examples or
Names and product codes:
It is not allowed to copy this.

Ventiliatorius spal / Ventilators spal
Vifte spal/wentylator spal/ventilador spal
Tagahanga spal/fläkt VA01-BP70/LL-36S spal/Ventilátor spal
Ventilator Spal/ventilatoretifoz Spal/azarkes Spal
Tuuletin Spal/ventilátor Spal/penggemar spal
Ventilador Spal/fano Spal /ventilaator Spal
Ventilators spal/ventiliatorius spal VA01-BP70/LL-36S
AC-3031588325/AC3031588325
AC 3031588325
AC-3010.2546/AC3010.2546
AC 3010.2546
AC-30102546/AC30102546
AC 30102546
AC-VA01-BP70/LL-36S/VA01BP70/LL36S
VA01BP70/LL-36S/VA01-BP70/LL36S
VA01-BP70/LL-36S/VA01BP70/LL36S
